- İşlemci / Veriyolu
2 x Soket P (LGA 3647)
1. ve 2.Nesil Xeon® Ölçeklenebilir İşlemci Ailesi
* Daha fazla bilgi için destek sayfasını ziyaret edin
- Core Logic
Intel® Lewisburg PCH C621
- Bellek
Toplam Slot Sayısı : 24 (6-channel per CPU, 12 DIMM per CPU)
Kapasite : Maksimum 3072GB RDIMM
Bellek Türü :
DDR4 2933/2666/2400 /2133 RDIMM
DDR4 2933/2666/2400 /2133 LRDIMM
DDR4 2933/2666/2400 /2133 LR-DIMM 3DS
DDR4 Intel® Optane™ DC Persistent Memory
Bellek Boyutu :
64GB, 32GB, 16GB RDIMM
128GB, 64GB, 32GB LRDIMM
128GB, 64GB LR-DIMM 3DS
* Daha fazla bilgi için destek sayfasını ziyaret edin
- Genişleme Yuvaları
Full-length/Full-height:
8 x PCI-E x16 (Gen3 x16 link), FH, FL
* Single root topology : 8 from CPU1
Dual root topology : 4 from CPU1, 4 from CPU2
Half-length/Low-profile:
Rear:
Dual root topology: 2 x PCI-E x16 (Gen3 x 16 link),LP,HL
(1 from CPU1,1 from CPU2)
or
Single root topology: 1 X PCI-E x16 (Gen3 x16 link),LP,HL
(from CPU1)
Front:
1 x PCI-E x8 (Gen3 x8 link),LP,HL (from CPU2)
- Depolama
SATA Kontrolcüsü :
Intel® C621
8 x SATA3 6Gb/s ports + 2 x M.2 connector (SATA 6Gb/s & PCIe® Gen3 x4 link 22110/2280/2260)
or
6 x SATA3 6Gb/s ports + 2 x NVMe drives + 2 x M.2 connector (SATA 6Gb/s & PCIe® Gen3 x4 link 22110/2280/2260)
Intel® Rapid Storage Teknolojisi - Kurumsal (RSTe) (Linux/Windows için)
(RAID Yazılım Desteği 0, 1, 5, 10 )
Intel®VROC (Linux/Windows için)
(RAID Yazılım Desteği 0/1 )
Optional kits Controller :
ASUS PIKEII 3008-8i 8-port SAS HBA
ASUS PIKE II 3108 8-port SAS HW RAID card
12G SAS Support
- HDD Bays
8 x Hot-swap 2.5" Storage Bays
(Storage bay 1 & 2 support NVMe/SATA/SAS* drives, Storage bay 3~8 support SATA/SAS* drives. Storage bay location numbers are from top to bottom. *SAS from optional ASUS PIKE II 3108/3008 cards.)
- Network
1 x Dual Port Intel I350-AM2 Gigabit LAN controller + 1 x Mgmt LAN
- Grafik
Aspeed AST2500 with 64MB VRAM
- Ön Giriş/Çıkış Portları
2 x USB 3.0 ports
2 x USB 2.0 ports
1 x VGA port
1 x COM port
- Rear I/O Ports
2 x RJ-45 GbE LAN ports
1 x RJ-45 Mgmt LAN port
- Switch/LED
Front Switch/LED:
1 x Q-Code/Port 80 LED
1 x Power switch/LED
1 x Location switch/LED
1 x HDD Access LED
1 x Message LED
Front Switch/LED:
1 x Q-Code/Port 80 LED
1 x Power switch/LED
1 x Location switch/LED
1 x HDD Access LED
1 x Message LED
2 x LAN LED
- İşletim Sistemi Desteği
Please find the latest OS support asus.com
- Yönetim Çözümleri
ACC
On-Board ASMB9-iKVM for KVM-over-IP
- Regulatory Compliance
BSMI, CE, FCC(Class A)
- Boyutlar
798mm x 439mm x 175.6mm (4U)
31.42" x 17.22" x 6.92"
- Form Faktörü
4U
- Güç Kaynağı
2+1 Redundant 1600W 80PLUS Platinum Power Supply;
100-127 / 200-240Vac, 12.9 / 9.5A（for each
inlet）, 47-63Hz, Class I
2+1 Redundant 2200W 80PLUS Platinum Power Supply
Rating: 100-127/200-240 Vac, 12.9/9.5 A (for each inlet), 47-63 Hz, Class I
*2200W Power supply is only available for selected countries.
- Çevre
Operation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
