Performans
Video giriş kanalı
The number of channels for video input that the device features.
8 kanallar
Alarm giriş kanalı
8
Alarm çıkış kanalı
1
Video kaydetme modu
720p, 1080p, 2160p
Maksimum çözünürlük
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
3840 x 2160 Piksel
Desteklenen çözünürlükler
3840x2160,1920x1080, 1680x1050, 1440x900, 1280x1024, 1024x768, 1280x720
Yakalama hızınde çözünürlük
1280x720@60fps, 1920x1080@60fps, 3840x2160@30fps
Desteklenen video formatları
The type of video formats that can be used by this device.
H.264, H.264+, H.265, H.265+
Giriş bant genişliği
80 Mbit/s
Çıkış bant genişliği
60 Mbit/s
Kablosuz LAN özellikleri
Wi-Fi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Depolama birimi
Maksimum saklama kapasitesi
The maximum amount of data that can be stored in the device.
10 TB
Sabit bellek arayüzü
The way that a hard disk drive (HDD) is connected to the rest of the computer through a 'bus' such as ATA or SCSI.
SATA
Bağlantı
Ethernet LAN (RJ-45) port sayısı
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
HDMI çıkışı
The device features an HDMI output.
HDMI port sayısı
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
1
VGA (D-Sub) çıktı yerleri
1
Bağlantı
USB 2.0 bağlantı noktası sayısı
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
2
Ses RCA girişleri
1
Ses RCA çıkışları
1
Fiber kanal protokolleri
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
TCP/IP, DHCP, DNS, NTP, UPnP
Özellikler
İletişim LED göstergeleri
Ürün rengi
The colour e.g. red, blue, green, black, white.
Siyah
Enerji yönetimi
Güç tüketimi
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
4,82 W
Çıkış akımı
2,43 A
Çalıştırma voltajı
53.5 V
Ethernet bütçesi üzerindeki toplam güç
119 W
Çevresel koşullar
Çalışma ısısı aralığı
The minimum and maximum temperatures at which the product can be safely operated.
-10 - 55 °C
Ağırlık & boyutlar
Genişlik
The measurement or extent of something from side to side.
294 mm
Derinlik
The distance from the front to the back of something.
180 mm
Yükseklik
The measurement of the product from head to foot or from base to top.
44 mm
