VSP4900- 12MXU-12XE	VSP4900-24XE	VSP4900-24S	VSP4900-48P
Performance and Scaling
Max Active 10/100/ 1000Mb Ports	N/A	0	0	48
Max Active 100M/1Gb/ 2.5Gb/5Gb/ 10Gb Ports	12	0	0	0
Max Active 100M/1Gb SFP ports	0	24	0	0
Max Active 1/10Gb SFP+ ports	16	28	4	4
Max Active 10/ 25Gb SPF28 ports	4	4	2	2
Max Active 40Gb QSFP+ ports*	2	2	1	1
Aggregated Switch Bandwidth	680 Gbps	680 Gbps	148 Gbps	196 Gbps
Frame Forwarding Rate	505.9 Mpps	505.9 Mpps	110.1 Mpps	145.8 Mpps
External Ports/Slot
Ports/Slots	12 x 1/2.5/5/10GBASE-T 802.3bt Type3 (60w) ports 12 x 1/10GBASE-X SFP+ ports (unpopulated) MACsec capable (256-bit) 1 x Serial (console port RJ-45) 1 x 10/100/1000BASE-T out-of-band management port 1 x USB Micro-B management port 2 x USB A ports for external USB flash 1 VIM5 slot	24 x 1/10GBASE-X SFP+ ports (unpopulated) LRM and MACsec capable (256-bit) 1 x Serial (console port RJ-45) 1 x 10/100/1000BASE-T out-of-band management port 1 x USB Micro-B management port 2 x USB A ports for external USB flash 1 VIM5 slot	24 x 100/1000BASE-X SFP ports (unpopulated) 1 x Serial (console port RJ-45) 1 x 10/100/1000BASE-T out-of-band management port 1 x USB Micro-B management port 2 x USB A ports for external USB flash 1 VIM5 slot	48 x 10/100/1000BASE-T 802.3at (30w) ports Full / Half-Duplex MACsec capable (128-bit) 1 x Serial (console port RJ-45) 1 x 10/100/1000BASE-T out-of-band management port 1 x USB Micro-B management port 2 x USB A ports for external USB flash 1 VIM5 slot
VIM Modules
VIM Modules	VIM5-4X: 4 x 1/10GBASE-X SFP+ (unpopulated ports) VIM5-4XE: 4 x 1/10GBASE-X SFP+ (unpopulated ports) LRM capable MACsec capable (256-bit) VIM5-2Y: 2 x 10/25GBASE-X SFP28 (unpopulated ports) VIM5-4Y: 4 x 10/25GBASE-X SFP28 (unpopulated ports) VIM5-4YE: 4 x 10/25GBASE-X SFP28 (unpopulated ports) MACsec capable (256-bit) VIM5-2Q: 2 x 40GBASE-X QSFP+ (unpopulated ports)
Physical Specifications
Dimensions	17.34 in W / 1.7 in H / 19.23 in D 440mm / 43.6mm / 488mm	17.34 in W / 1.7 in H / 19.23 in D 440mm / 43.6mm / 488mm	17.34 in W / 1.7 in H / 19.23 in D 440mm / 43.6mm / 488mm	17.34 in W / 1.7 in H / 19.23 in D 440mm / 43.6mm / 488mm
Net Weight	16.67 lb / 7.58 kg	16.89 lb / 7.66 kg	18.01 lb / 8.17 kg	18.49 lb / 8.39 Kg
Minimum/Maximum Power Consumption and Heat Dissipation
Minimum Power Consumption (Watts)	73	80	52	74
Minimum Heat Dissipation (BTU/hr)	250	271	179	254
Maximum Power Consumption (Watts)1	970	207	173	1746
Maximum Heat Dissipation (BTU/hr)2	854	707	590	1046

Performance and Scale

Memory
- VSP4900-48P and VSP4900-24S
  - 2GB DRAM / 8GB eMMC NVRAM
- VSP4900-12MXU-12XE and VSP4900-24XE
  - 8GB DRAM / 8GB eMMC NVRAM
Layer 2
- MAC Address: up to 80,000
- Port-based VLANs: 4,059
- MSTP Instances: 12
- LACP Links per Group: 8 Active
Layer 3 IPv4 Routing Services
- ARP Entries: up to 32,000
- IP Routes: up to 15,488
- RIP Interfaces: 200
- OSPF Interfaces: 500
- BGP Peers: 256
- VRF Instances: up to 256
- Layer 3 IPv6 Routing Services
- Neighbors: up to 8,000
- IP Routes: up to 7,744
- RIPng Interfaces: 48
- OSPFv3 Interfaces: 500
- BGPv6 Peers: 256
- VRF Instances: up to 256
Multicast
- IGMP Interfaces: 4,059
- PIM Active Interfaces: 128
- MLD Interfaces: 4,059
- IP Multicast Streams: 6,000
Fabric Connect
- MAC Address: 40,000
- NNI Interfaces/Adjacencies: up to 255
- BEB Nodes per VSN: 500
- BCB/ BEB Nodes per Region: 550
- L2 Virtual Service Networks: 4,059
- L3 Virtual Service Networks: up to 256
- IP Shortcut Routes: IPv4 up to 15,488 and IPv6 7,488
- L2 Multicast Virtual Service Networks: 2,000
- L3 Multicast Virtual Service Networks: 256
- Maximum SGVs: 6,000
QoS and Filtering
- IPv4 ACE: 1536 (1024 Security + 512 QOS) Ingress and 248 Egress
- IPv6 ACE: 1024 Ingress and 256 Egress
- QoS priority queues- 8
Operations and Management
- Mirrored Ports: 49
- sFlow: up to 3100 samples per second
- Fabric RSPAN: 1,000 VLAN IDs

Environmental

Environmental Specifications
- EN/ETSI 300 019-2-1 v2.1.2 - Class 1.2 Storage
- EN/ETSI 300 019-2-2 v2.1.2 - Class 2.3 Transportation
- EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e Operational
- EN/ETSI 300 753 (1997-10) - Acoustic Noise
- ASTM D3580 Random Vibration Unpackaged 1.5 G
Environmental Compliance
- EU RoHS 2011/65/EU
- EU WEEE 2012/19/EU
- China RoHS SJ/T 11363-2006
- Taiwan RoHS CNS 15663(2013.7)
Operating Conditions
- Temp: 0° C to 45° C (32° F to 113° F)
- Humidity: 10% to 95% relative humidity, non-condensing
- Altitude: 0 to 3,000 meters (9,850 feet)
- Shock (half sine) 30m/s2 (3G), 11ms, 60 shocks
- Random vibration: 3 to 500 Hz at 1.5 G rms
Packaging and Storage Specifications
- Temp: -40° C to 70° C (-40° F to 158° F)
- Humidity: 10% to 95% relative humidity, non-condensing
- Packaged Shock (half sine): 180 m/s2 (18 G), 6 ms, 600 shocks
- Packaged Vibration: 5 to 62 Hz at velocity 5 mm/s, 62 to 500 Hz at 0.2 G
- Packaged Random Vibration: 5 to 20 Hz at 1.0 ASD w/–3 dB/oct. from 20 to 200 Hz
- Packaged Drop Height: 14 drops minimum on sides and corners at 42 inches (<15 kg box)

Regulatory and Safety

North American ITE
- UL 60950-1
- UL 62368-1
- Complies with FCC 21CFR 1040.10 (U.S. Laser Safety)
- CDRH Letter of Approval (US FDA Approval)
- CAN/CSA 22.2 No. 60950-1
- CAN/CSA No. 22.2 62368-1-14
European ITE
- EN 60950-1, EN 62368-1
- EN 60825-1Class 1 (Lasers Safety)
- 2014 / 35/ EU Low Voltage Directive
International ITE
- CB Report & Certificate per IEC 60950-1 AS/NZS 60950-1 (Australia /New Zealand)
- IEC 62368-1
- GB 4943.1-2011
- CNS 14336-1

EMI/EMC Standards

North American EMC for ITE
- FCC CFR 47 part 15 Class A (USA)
- ICES-003 Class A (Canada)
European EMC Standards

EN 55032 Class A
EN 55024
EN 55035
EN 61000-3-2,2014 (Harmonics)
EN 61000-3-3 2013 (Flicker)
EN 300 386 v1.6.1 (EMC Telecommunications)
2014/30/EU EMC Directive
EN 55011 Class A

International EMC Certifications
- CISPR 32, Class A (International Emissions)
- AS/NZS CISPR32
- CISPR 24 Class A (International Immunity)
- IEC 61000-4-2 / EN 61000-4-2 Electrostatic Discharge, 8kV Contact, 15 kV Air, Criteria A
- IEC 61000-4-3 /EN 61000-4-3 Radiated Immunity 10V/m, Criteria A
- IEC 61000-4-4 / EN 61000-4-4 Transient Burst, 1 kV, Criteria A
- IEC 61000-4-5 /EN 61000-4-5 Surge, 2 kV L-L, 2 kV L-G, Level 3, Criteria A
- IEC 61000-4-6 Conducted Immunity, 0.15-80 MHz, 10V/m unmod. RMS, Criteria A
- IEC/EN 61000-4-11 Power Dips & Interruptions, >30%, 25 periods, Criteria C
- IEC 61000-4-8 / EN 61000-4-8
- CISPER 11 Class A
- GB/T 9254-2008
Country Specific
- VCCI Class A (Japan Emissions)
- ACMA RCM (Australia Emissions)
- CCC Mark (China)
- KCC Mark, EMC Approval (Korea)
- EAC Mark (Custom Union)
- NRCS / ICASA Mark (South Africa)
- BSMI Mark (Taiwan)
Telecom Standards
- CE 2.0 Compliant

IEEE 802.3 Media Access Standards

IEEE 802.3ab 1000BASE-T
IEEE 802.3ae 10GBASE-X
IEEE 802.3aq 10GBASE-LRM
25Gb Ethernet implemented per Ethernet Consortium specification and IEEE 802.3 standard
IEEE 802.3ba / 802.3bm 40GBASE-X
IEEE 802.3at PoE Plus
IEEE 802.3az Energy Efficient Ethernet
