VSP7400-48Y-8C-ACF Anahtarlama Cihazı Switch-VSP 7400 48 x 10/25Gbps SFP28 ports 8 x

General

• VSP7400-32C
  • Physical Connectivity: 32 x QSFP28 ports
  • Switch Fabric Architecture: 6.4 Tbps total capacity (3.2 Tbps ingress, 3.2 Tbps egress)
  • Jumbo Frame support up to 9.600 bytes
• VSP7400-48Y-8C
  • Physical Connectivit y: 48 X SFP28 port s + 8 x QSFP28 ports
  • Switch Fabric Architecture: 4.0 Tbps total capacity (2.0 Tbps ingress, 2.0 Tbps egress)
  • Jumbo Frame support up to 9,600 bytes

Performance and Scale

• Layer 2
  • MAC Address: up to 160,000
  • Port-based VLANs: 4,0 59
  • MSTP Instances: 64
  • LACP Links per Group: 8 Active
• Layer 3 IPv4 Routing Services
  • ARP Entries: up to 56,000
  • IP Routes: up to 16,000
  • RIP Interfaces: 200
  • OSPF Interfaces: 512
  • BGP Peers: 256
  • VRF Instances: up to 256
• Layer 3 IPv6 Routing Services
  • Neighbors: up to 32,000
  • IP Routes: up to 7,500
  • RIPng Interfaces: 48
  • OSPFv3 Interfaces: 500
  • BGPv6 Peers: 256
  • VRF Instances: up to 256
• Multicast
  • IGMP Interfaces: 4,059
  • PIM Active Interfaces: 128
  • MLD Interfaces: 4,059
  • IP Multicast Streams: 6,000
• Fabric Connect
  • MAC Address: 80,000
  • NNI Interfaces/Adjacencies: up to 256
  • BEB Nodes per VSN: 2,000
  • BCB/ BEB Nodes per Region: 2,000
  • L2 Virtual Service Networks: 4,000
  • L3 Virtual Service Networks: up to 256
  • IP Shortcut Routes: IPv4 up to 16,000 and IPv6 7,500
  • L2 Multicast Virtual Service Networks: 2,000
  • L3 Multicast Virtual Service Networks: 256
• QoS and Filtering
  • ACL non-IPv6: 512 Ingress and 254 Egress
  • ACL IPv6: 384 Ingress and 256 Egress
  • IPv4 ACE (Ingress): 768 each for Security and QoS (total of 1536)
  • IPv4 ACE (Egress): 507
  • IPv6 ACE (Ingress): 767
  • IPv6 ACE (Egress): 511
  • Egress Port Shaper Granularity: 1Mbps to 100 Gbps per Port
• Operations and Management
  • Mirrored Ports: up to 125 when all applicable port s are channelized
  • sFlow: up to 3,000 samples per second
  • Fabric RSPAN: up to 1,000 VSN IDs per Region

Environmental

• Environmental Specifications
  • EN/ETSI 3000 19-2-1v2.1.2 - Class 1.2 Storage
  • EN/ETSI 3000 19-2-2 v2.1.2 - Class 2.3 Transportation
  • EN/ETSI 3000 19-2-3 v2.1.2 - Class 3.1e Operational
  • EN/ETSI 300 753 (1997-10 ) - Acoustic Noise ASTM D3580 Random Vibration Unpackaged 1.5 G
• Environmental Compliance
  • EU RoHS: 20 11/ 65/ EU
  • EU W EEE: 20 12/ 19/ EU
  • China RoHS: SJ/ T 11363-2006
  • Taiwan RoHS: CNS 15663(2013.7)
• Packaging and Storage Specifications
  • Temp: -40 ° C to 70 ° C (-40 ° F to 158° F)
  • Humidity: 10 % to 95% relative humidity, non-condensing
  • Packaged Shock (half sine): 180 m/s2 (18 G), 6 ms, 600 shocks
  • Packaged Vibration: 5 to 62 Hz at velocity 5 mm/ s, 62 to 500 Hz at0.2G
  • Packaged Random Vibration: 5 to 20 Hz at 1.0 ASD w/ -3 dB/ oct. from 20 to 200Hz
  • Packaged Drop Height: 14 drops minimum on sides and corners at 42 inches (<15 kg box)

Regulatory and Safety

• North American ITE
  • UL 60950-1
  • UL 62368-1
  • Complies with FCC 21CFR 1040.10 (U.S. Laser Safety)
  • CDRH Letter of Approval (US FDA Approval)
  • CAN/CSA 22.2 No. 60950-1
  • CAN/CSA No. 22.2 62368-1-14
• European ITE
  • EN 60950-1, EN 62368-1
  • EN 60825-1Class 1 (Lasers Safety)
  • 2014 / 35/ EU Low Voltage Directive
• International ITE
  • CB Report & Certificate per IEC 60950-1 AS/NZS 60950-1 (Australia /New Zealand)
  • IEC 62368-1
  • GB 4943.1-2011
  • CNS 14336-1
• EMI/EMC Standards North American EMC for ITE
  • FCC CFR 47 Part 15 Class A (USA)
  • ICES-003 Class A (Canada)
• European EMC Standards
  • EN 55032 Class A
  • EN 55024
  • EN 61000-3-2,2014 (Harmonics)
  • EN 61000 -3-32013 (Flicker)
  • EN 300 386 v1.6.1(EMC Telecommunications)
  • 2014/30/EU EMC Directive
  • EN 55011Class A
• International EMC Certifications
  • CISPR 32, Class A (International Emissions)
  • AS/ NZS CISPR32
  • CISPR 24 Class A (International Immunity)
  • IEC 61000-4-2 / EN 61000-4-2 Electrostatic Discharge, 8kV Contact, 15 kV Air, Criteria A
  • IEC 61000-4-3 / EN 61000-4-3 Radiated Immunit y 10V/ m, Criteria A
  • IEC 61000-4-4 / EN 61000-4-4 Transient Burst, 1kV, Criteria A
  • IEC 61000-4-5 / EN 61000-4-5 Surge, 2 kV L-L, 2 kV L-G, Level 3, Criteria A
  • IEC 61000-4-6 Conducted Immunit y,0 .15-80 MHz, 10V/ m unmod. RMS, Criteria A
  • IEC/ EN 61000 -4-11Power Dips & Interruptions, >30 %, 25 periods, Criteria C
  • IEC 61000-4-8 / EN 61000-4-8
  • CISPER 11Class A
  • GB/T 9254-200 8
• Country Specific
  • VCCI Class A (Japan Emissions)
  • ACMA RCM (Australia Emissions)
  • CCC Mark (China)
  • KCC Mark, EMC Approval (Korea)
  • EAC Mark (Custom Union)
  • NRCS / SABS Mark (South Africa)
  • BSMI Mark (Taiwan)
• Telecom Standards
  • CE 2.0 Compliant

Standards Compliance

• IEEE 802.1Bridging (Networking) and Network Management
  • 802.1D MAC Bridges (a.k.a. Spanning Tree Protocol)
  • 802.1p Traffic Class Expediting and Dynamic Multicast Filtering
  • 802.1t 802.1D Maintenance
  • 802.1w Rapid Reconfiguration of Spanning Tree (RSTP)
  • 802.1Q Virtual Local Area Networking (VLAN)
  • 802.1Qbp Equal-Cost Multi-Path (Shortest Path Bridging)
  • 802.1Qcj Automatic Attachment to Provider Backbone Bridging (PBB) Services (Partial Support)
  • 802.1s Multiple Spanning Trees (MSTP)
  • 802.1v VLAN Classification by Protocol & Port
  • 802.1ag Connectivit y Fault Management
  • 802.1ah Provider Backbone Bridges
  • 802.1aq Shortest Path Bridging (SPB) MAC-in-MAC
  • 802.1X Port-based Network Access Control
  • 802.1AB-2005 Station & Media Access Control Connectivit y Discovery; aka LLDP (partial support)
  • 802.1AX Link Aggregation
• 802.3 Ethernet
• 802.3-1983 CSMA/ CD Ethernet (ISO/ IEC 8802-3)
• 802.3i-1990 10Mb/ s Operation, 10BASE-T Copper
• 802.3u-1995 100Mb/ s Operation, 100BASE-T Copper, with Auto-Negotiation
• 802.3x-1997 Full Duplex Operation
• 802.3z-1998 1000Mb/s Operation, implemented as 1000BASE-X
• 802.3ab-1999 1000Mb/s Operation, 1000BASE-T Copper
• 802.3ae-2002 10Gb/s Operation, implemented as 10GBASE-SFP+
• 802.3an-2006 10Gb/s Operation, 10GBASE-T Copper
• 802.3ba-2010 40Gb/s and 100Gb/s Operation
• 802.3bm-2015 40Gb/ s and 100Gb/s Operation, implemented as 40GBASE-QSFP+ & 100 GBASE-QSFP28
• IETF
  • 768 UDP
  • 783 TFTP
  • 791 IP
  • 792 ICMP
  • 793 TCP
  • 826 ARP
  • 854 Telnet
  • 894 Transmission of IP Datagrams over Ethernet Networks
  • 896 Congestion Control in IP/ TCP internetworks
  • 906 Boot strap Loading using TFTP
  • 950 Internet Standard Subnetting Procedure
  • 951 BOOTP: Relay Agent-only
  • 959 FTP
  • 1027 Using ARP to Implement Transparent Subnet Gateways
  • 1058 RIP
  • 1112 Host Extensions for IP Multicasting
  • 1122 Requirement s for Internet Host s - Communication Layers
  • 1155 Structure and Identification of Management Information for TCP/ IP-based Internets
  • 1156 MIB for Network Management of TCP/ IP
  • 1157 SNMP
  • 1212 Concise MIB Definitions
  • 1213 MIB for Network Management of TCP/ IP-based Internets: MIB-II
  • 1215 Convention for Defining Traps for use with the SNMP
  • 1256 ICMP Router Discovery
  • 1258 BSD Rlogin
  • 1271 Remote Network Monitoring MIB
  • 1305 NTPv3
  • 1321 MD5 Message-Digest Algorithm
  • 1340 Assigned Numbers
  • 1350 TFTPv2
  • 1398 Ethernet MIB
  • 1442 SMIv2 of SNMPv2
  • 1450 SNMPv2 MIB
  • 1519 CIDR
  • 1541 DHCP
  • 1542 Clarifications and Extensions for BOOTP
  • 1573 Evolution of the Interfaces Group of MIB-II
  • 1587 OSPF NSSA Option
  • 1591 DNS Client
  • 1650 Definitions of Managed Object s for the Ethernet-like Interface Types
  • 1657 Definitions of Managed Object s for BGP-4 using SMIv2
  • 1723 RIPv2 Carrying Additional Information
  • 1812 Router Requirements
  • 1850 OSPFv2 MIB
  • 1866 HTMLv2
  • 1907 SNMPv2 MIB
  • 1930 Guidelines for creation, selection, and registration of an AS
  • 1981 Path MTU Discovery for IPv6
  • 2021Remote Network Monitoring MIBv2 using SMIv2
  • 2068 HTTP
  • 2080 RIPng for IPv6
  • 2131 DHCP
  • 2138 RADIUS Authentication
  • 2139 RADIUS Accounting
  • 2139 RADIUS Accounting
  • 2236 IGMPv2 Snooping
  • 2284 PPP Extensible Authentication Protocol
  • 2328 OSPFv2
  • 2362 PIM-SM
  • 2404 HMAC-SHA-1-96 within ESP and AH6
  • 2407 Internet IP Securit y Domain of Interpretation for ISAKMP6
  • 2408 Internet Securit y Association and Key Management Protocol
  • 2428 FTP Extensions for IPv6 and NAT
  • 2452 TCP IPv6 MIB
  • 2453 RIPv2
  • 2454 UDP IPv6 MIB
  • 2460 IPv6 Basic Specification
  • 2463 ICMPv6
  • 2464 Transmission of IPv6 Packet s over Ethernet Networks
  • 2466 MIB for IPv6: ICMPv6 Group
  • 2474 Differentiated Services Field Definitions in IPv4 and IPv6 Header
  • 2575 VACM for SNMP
  • 2576 Coexistence between v1/ v2/ v3 of the Internet-standard Network Management Framework
  • 2578 SMIv2
  • 2579 Textual Conventions for SMIv2
  • 2580 Conformance Statement s for SMIv2
  • 2597 Assured Forwarding PHB Group
  • 2598 Expedited Forwarding PHB
  • 2616 HTTPv1.1
  • 2710 MLD for IPv6
  • 2716 PPP EAP TLS Authentication Protocol
  • 2787 Definitions of Managed Object s for VRRP
  • 2818 HTTP over TLS
  • 2819 Remote Network Monitoring MIB
  • 2863 Interfaces Group MIB
  • 2865 RADIUS
  • 2869 RADIUS Extensions (partial support)
  • 2874 DNS Extensions for IPv6
  • 2925 Definitions of Managed Object s for Remote Ping, Traceroute, and Lookup Operations
  • 2933 IGMP MIB
  • 2934 PIM MIB for IPv4
  • 2992 ECMP Algorithm 30 46 DHCP Relay Agent Information Option 82
  • 3162 RADIUS and IPv6
  • 3246 Expedited Forwarding PHB
  • 3315 DHCPv6
  • 3339 Date and Time on The Internet: Timestamps
  • 3376 IGMPv3
  • 3411Architecture for Describing SNMP Management Frameworks
  • 3412 Message Processing and Dispatching for SNMP
  • 3413 SNMP Applications
  • 3414 USM for SNMPv3
  • 3415 VACM for SNMP
  • 3416 Protocol Operations v2 for SNMP
  • 3417 Transport Mappings for SNMP
  • 3418 MIB for SNMP
  • 3484 Default Address Selection for IPv6
  • 3513 IPv6 Addressing Architecture
  • 3569 Overview of SSM
  • 3579 RADIUS Support for EAP
  • 3587 IPv6 Global Unicast Address Format
  • 3596 DNS Extensions to support IPv6
  • 3748 Extensible Authentication Protocol
  • 3810 MLDv2 for IPv6
  • 3879 Deprecating Site Local Addresses
  • 4007 IPv6 Scoped Address Architecture
  • 4022 TCP MIB
  • 4087 IP Tunnel MIB
  • 4113 UDP MIB
  • 4133 Entit y MIB Version 3 (partial support)
  • 4193 Unique Local IPv6 Unicast Addresses
  • 4213 Basic Transit ion Mechanisms for IPv6 Hosts and Routers
  • 4250 SSH Assigned Numbers
  • 4251 SSH Protocol Architecture
  • 4252 SSH Authentication Protocol
  • 4253 SSH Transport Layer Protocol
  • 4254 SSH Connection Protocol
  • 4255 DNS to Securely Publish SSH Key Fingerprints
  • 4256 Generic Message Exchange Authentication for SSH
  • 4291 IPv6 Addressing Architecture
  • 4292 IP Forwarding Table MIB
  • 4293 IP MIB
  • 4301 Securit y Architecture for IP1
  • 4302 IP Authentication Header1
  • 4303 IP Encapsulating Securit y Payload1
  • 4308 Cryptographic Suites for IPsec
  • 4363 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering and VLAN Extensions (partial support)
  • 4429 Optimistic DAD for IPv6 (partial support)
  • 4443 ICMP for IPv6
  • 4541Considerations for IGMP and MLD Snooping Switches
  • 4552 Authentication/ Confidentiality for OSPFv3
  • 4601 PIM-SM: Revised Protocol Specification
  • 4607 Source-Specific Multicast for IP
  • 4675 RADIUS Attributes for Virtual LAN and Priority Support (partial support)
  • 4835 Cryptographic Algorithm Implementation Requirement s for ESP and AH
  • 4861Neighbor Discovery for IPv6
  • 4862 IPv6 Stateless Address Auto-Configuration
  • 5095 Deprecation of Type 0 Routing Headers in IPv6
  • 5176 Dynamic Authorization Extensions to RADIUS
  • 5187 OSPFv3 Graceful Restart (Helper-mode)
  • 5308 Routing IPv6 with IS-IS 5340 OSPF for IPv6
  • 5424 The Syslog Protocol
  • 5798 VRRPv3 for IPv4 and IPv6
  • 5905 NTPv4: Protocol and Algorithms Specification
  • 5997 Use of Status-Server Packets in RADIUS
  • 6105 IPv6 Router Advertisement Guard
  • 6329 IS-IS Extensions supporting IEEE 80 2.1aq SPB
  • 6933 Entit y MIBv4 (partial support)
  • 7358 VXLAN: A Framework for Overlaying Virtualized L2 Networks over L3 Networks (partial support)
  • 7610 DHCPv6 Shield: Protecting against Rogue
  • DHCPv6 Servers
  • Iernet-Draft IP/ IPVPN services with IEEE 80 2.1aq SPB networks (draft-unbehagen-spb-ip-ipvpn-00)
  • Internet-Draft SPB Deployment Considerations (draft-lapuh-spb-deployment-03)
